MITUTOYO - Surface Roughness Tester (SJ-210) (178-561-2E) + FREE CALIBRATION CERTIFICATE

MITUTOYO - Surface Roughness Tester (SJ-210) (178-561-2E) + FREE CALIBRATION CERTIFICATE

19 sold in last 24 hours

Rs. 121,500.00 (Incl. GST)
Rs. 102,966.10 (Excl. GST)
Rs. 130,000.00

Discount: Rs. 8,500.00 (7%)

Parameter Specification
Product Mitutoyo Surface Roughness Tester SJ‑210
Make Mitutoyo
Model SJ‑210
Order Number (Example) 178‑561‑02E (4 mN type)
Measuring Range (Z‑axis) 360 µm (‑200 µm to +160 µm); other selectable ranges: 100 µm, 25 µm
X‑Axis Traverse Approx. 17.5 mm (0.69 in) or 5.6 mm (0.22 in) depending on drive unit type
Measurement Speed 0.25, 0.50, 0.75 mm/s (measuring) / 1 mm/s (return)
Resolution 0.02 µm, 0.006 µm, 0.002 µm (depending on range)
Measuring Force 0.75 mN or 4 mN depending on detector type
Skid Force < 400 mN
Applicable Standards JIS ’82, JIS ’94, JIS ’01, ISO ’97, ANSI, VDA
Evaluation Parameters Ra, Rc, Ry, Rz, Rq, Rt, Rmax, Rp, Rv, R3z, Rsk, Rku, RPc, Rsm, RzJIS, etc.
Measurement Unit Metric / Inch selectable

FEATURES

• Portable surface roughness tester for on‑site measurement
• Measures a wide range of roughness parameters (Ra, Rz, Rq, etc.)
• Multiple detector force options (0.75 mN / 4 mN) to suit surface types
• Multiple resolution settings for fine to coarse surface assessment
• Conforms to major international standards (ISO, JIS, ANSI, VDA)
• User‑friendly with color LCD display and multi‑language support
• Battery (rechargeable) and AC adapter operation options
• Data output via USB and other communication interfaces (optional)
