Description
* Screen Diameter 300mm. fine ground screen with cross line. Rotatable 0 to 360˚ vernier reading 2 minutes.
* Magnification 10x & 20x .
* Magnification Accuracy ± 0.1% for contour and ± 0.15% for surface
* Work Stage Table 150x150mm. X & Y axis, Traverse 25mm in each direction having least count .01mm
* Contour Illumination 24V – 150W Halogen Lamp. Telecentric system and sharp twin lens condenser for each magnification bright adjustment
* Surface Illumination. 12V – 50W Halogen lamp with reflector
* Power Supply220 / 240V AC., 50 / 60Hz., Fuse 5A.
* Cooling System Built in noiseless and vibration free blower for powerful cooling system
Additional Information
SPECIFICATIONS –
Screen Diameter 300mm. fine ground screen with cross line.
Magnification 10x
Magnification Accuracy ± 0.1% for contour and ± 0.15% for surface.
Work Stage (Threadless) Table Size: 300x200mm, X & Y axis. Travel :150mm x 100mm.
Contour Illumination 24V – 150W Halogen Lamp. Telecentric system and sharp twin lens
condenser for each magnification brightness adjustment.
Focusing Mechanism Manual.
Surface Illumination 12V – 50W Halogen lamp With Reflector.
Cooling System Built in noiseless and vibration free blower for powerful cooling
system.
Power Supply 230V Single Phase AC.
Digital Readout System
With 2nos. Linear Glass Scale Res. 1 Micron With 3 -Axis Display Unit &
Digital Encoder For Angular Measurement.
With Radius Interface.
