Description
General Specifications
Jaw Opening : Cable Dia 55mm (approx.), 64 x 24 mm (Bus Bar)
Display : 4 + 4 digits LCD
Battery Type : 1.5 V SUM - 3 x 2
Weight : 650 gms (approx.) Battery Included
Dimensions : 271 x 112 x 46 mm
Additional Information
POWER ANALYSIS :
- W, KW, HP, VA, KVA, VAR, KVAR
- PF, Phase Angle (Φ)
- Energy (WH, KWH)
- Balanced 3Φ Power Quality
- Balanced 3Φ Sequence
- Programmable CT Ratio (1 to 250)
- Dual Displays (W + PF, VA + KVAR...)
- Active power in HP
- Resistance and Continuity with Beeper
HARMONICS ANALYSIS :
- True RMS value (V and A) at 0.5% basic accuracy
- 1500 A AC
- Harmonics Analysis (V and A) to the 99th Order in % and in magnitude
- Better Understaning of High Frequency Harmonic Analysis (up to 5/6/KHz)
- Non-interrupted Harmonic Analysis
- Analysis of Total Harmonic Distortion(%THD-F)
- Analysis of Crest Factor (C.F.)
- Fast Peak Function (33μs for 60Hz and 39μs for 50Hz)
- Max, Min & Data Hold Function
