Description
- 4 Line , 7 Segment LED Display
- 3 Ph-3W/4W
- 10 + Parameter with LED indication
- CT Selectable up to 4000/5
- RS-485 MODBUS Communication
Additional Information
| * Brand | MULTISPAN |
| * Model No | AVH-13N |
| * Dimension (H*W*D) mm | 96*96*50 |
| * Panel Cutout (mm) | 92*92 |
| * Input Signal | 3Ф 4 Wire |
| * Voltage | 300V AC (L-N) / 520V AC (P-P) |
| * Current | 5/5A to 6000/5A CT Ratio Selectable |
| * Voltage (L-L) | 50-500V AC |
| * Voltage (L-N) | 30-300V AC |
| * Current (-A) | 5/5 to 6000/5A CT Ratio Selectable |
| * KW Total | 0.000-9999Kw |
| * KWH Total | 000.000-999999KWH |
| * Power Factor Average (PF) | 0.100-1.000 |
| * KVA Total | 0.000-9999KVA |
| * Frequency (Hz) | 45-65 Hz |
| * KVAr Total | 0.000-9999KVAr |
| * Communication | RS-485 MODBUS (Optional) |
| * Accuracy | Class 1.0 |
| * Power Supply | 230V AC +/-10%,50Hz |
