WORKZONE - COATING THICKNESS GAUGE (DFT-222)

Alarm User can set the high/low alarm limit.
Alarm icon displayed on LCD when over the limit

Minimum curvature radius convex : 5mm
Minimum curvature radius concave : 25mm
Minimum measuring area Diameter : 20mm
Minimum thickness of substrate : 0.2mm (F) ; 0.2mm (NF)

Computer interface Download data via USB

Power supply Two 1.5V AAA battery

Operation environment Temperature: 0 to 50°C(32 to 122°F) : humidity: 20% to 90%rh

Storage environment Temperature: -10 to 60°C(14 to 140°F)

Standard Compliance CE ROHS FCC ISO2178 ISO2360

Size 110mm x 53mm x 24mm(4.33" x 2.09" x 0.94")

Case Material ABS ; 92g(3.24 oz)

Standard Accessories Coating Thickness Gauge, 'O' calibration block, Standard foil,
USB cable, Two l.5V AAA battery, Technical manual.
