Maxima-Low resistance jig (ZMLRJ)

Maxima-Low resistance jig (ZMLRJ)

7 sold in last 24 hours

Rs. 0.00

PRODUCT CODE:T/E/LRJ/MAX/XXX/001

Set of 4 wire Low Resistance standards Fixed resistors :
10µΩ, 50µΩ, 100µΩ, 1mΩ, 10mΩ, 100mΩ, 1000mΩ
Maximum Test currents :
For 10µΩ, 50µΩ : 20 A
For 100µΩ ,1mΩ : 10 A
For 100mΩ,10mΩ : 1A
For 1000mΩ : 100 mA
Accuracy class :
0.25% for 10µΩ, 50µΩ,0.1% for 100µΩ, 1mΩ, 10mΩ, 100mΩ, 1000mΩ
• Four wire low resistance standard is a source of fixed resistances of different values from micro-ohm to milliohm.
• Four wire measurements are best for low resistance measurements. Current is pumped (through A+ and A- binding posts) and voltage drop is measured (across V+ and V- binding posts). Using formula R=V/I, resistance is calculated.
Accessory : set of banana to banana cables of suitable length (2 red and 2 black)

Hurry Up! Only 10 Left in Stock!

In Stock Unavailable

T/E/LRJ/MAX/XXX/001
