Description
• Measuring insulation of open contacts of circuit breaker.
• Use it to test insulation resistance, on ceramic insulators,
between Bus Bars, high power transformer, HT Motors.
• Short circuit current upto 5mA.
• PI, DAR & Auto Hold Function.
• 2 Lines X 16 Characters large LCD Backlight display.
• 2 optical LEDs are built in for data transfer.
• Calendar.
• Internal memory for data storage.
• Optical USB to RS-232 data transmission.
• Well isolated to contact & Surge protection.
• Auto power off.
• Power supply : Rechargable battery.
• Dimension : 430(L) x 324(W) x 127(H) mm
Additional Information
• Microprocessor controlled Menu driven.
• Measuring 30 Insulation Test Voltage Ranges:
500V, 1kV, 1.5kV, 2kV, 2.5kV, 3kV, 3.5kV, 4kV, 4.5kV, 5kV, 5.5kV,
6kV, 6.5kV, 7kV, 7.5kV, 8kV, 8.5kV, 9kV, 9.5kV, 10kV, 10.5kV,
11kV, 11.5kV, 12kV, 12.5kV, 13kV, 13.5kV, 14kV, 14.5kV, 15kV.
• Maximum Insulation Resistance (5KV) : 2T Ω.
• AC / DC Voltage : 600V.
• Accuracy : ±5% rdg ± 1dgt.
• Realtime Clock.
• Warning Voltage Detection.
• Automatically Stops the Test.
• Guard Connection to reduce errors.
• Bargraph to indicate rise & decay of Voltage.
• Automatic Discharge of Circuits.
• Data recording facility : 200 measurements.
