Description
• Visual and audio warning of external voltage presence (≥30Vac or ≥30Vdc)
• Auto-hold function to freeze reading
• Overload protection
• Adjustable testing duration : 1~30 minutes
• Internal memory for data storage
• Displays testing duration for insulation measurement
• Auto-off function
• 200 measurement results can be saved in memory and recalled on display
• Power Supply 1.5V "C" × 8 Alkaline batteries
• Dimension 330(L) × 260(W) × 160(D)mm
• Weight Approx. 4284g (battery included)
• Accessories Instruction Manual, Test leads, Data transmission cable CA-232,
• Compact disk (CD) for PC interface, Alligator clip, Batteries, Test report
Additional Information
Special Features
• 2 Lines x 16 characters LCD
• Microprocessor-controlled.
• Tests insulation resistance up to 20 TΩ
• 4 Insulation test voltages : 1000V, 2500V, 5000V, 10000V
• AC / DC Voltmeter (30~600V)
• Short-circuit current up to 5mA
• PI (Polarization Index) indication
• DAR (Dielectric Absorption Ratio) indication
• Auto-ranging on all insulation ranges
• Optical USB to RS-232 data transmission
• Well isolated from contact
• Well protected from surges
• 2 built-in optical LEDs for data transfer
