KUSUMMECO - ANALOG INSULATION RESISTANCE TESTER (KM-03) (0 - 100 MO) +FREE CALIBRATION CERTIFICATE

RATED OUTPUT V (DC) - 500 V

SCALE RANGE - 0 - 100MΩ

ACV RANGE - 0 - 600 V

• Battery Operation
• Logarithmic Scale.
• Anti-parallax mirror scale for accurate readings.
• Power ON / OFF switch Lock for continuous measurement.
• Battery condition indication.
• Sturdy ABS case
• High Voltage (Output) LED Indicator
• Operating Temperature : 0°C-40°C, < 75%R.H.
• Storage Temperature : -10°C-60°C, < 80%R.H.
• Power ON/OFF Switch for continuous measurement
• AC Voltage measurement facility to check for live circuits.
• AC Voltage measurement Accuracy within ±5% of max. Scale value.
• Terminal- to- Terminal Voltage ± 10% of rated Voltage at "0" Megaohms scale.
  About 90% of rated Voltage at Center scale.
• Insulation Resistance Accuracy ± 5% indicated value
• Power Supply :Standard 1.5V x 4 batteries.
• Dimensions : 100 X 150 X 45 mm. Appx.
• Weight : 350 gms. Approx
